Static Boom Placer

Get a Price/Quote

Static Boom Placer Specification

Max Flow Rate
85 m3/h

Surface
Coated

Motor Power
15 kW

Max Pressure
32 MPa

MAX TIP SIZE
DN125

Lifting Speed
30 m/min

Rated Power
15 KW

Lifting Height
Up to 18 m

Application
High-rise Buildings, Bridges, Infrastructure Projects

Product Type
Static Boom Placer

General Use
Concrete Placement at Tough Locations in Construction Sites

Material
High-grade Steel

Type
Stationary Construction Machinery

Capacity
60-90 m3/h

Weight (kg)
5500 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Remote/Manual

Cooling System
Air Cooled

Method
Hydraulic Placing

Voltage
415 V

Dimension (L*W*H)
7500 mm x 2100 mm x 2300 mm

Feature
360-degree Rotation, Simple Operation, Low Maintenance

Color
Red

Mounting Type
Stationary Base

Boom Length
18 m

Swivel Range
360 Continuous

Number of Boom Sections
3

Pipe Diameter
125 mm

Rotation Range
360 Degrees

Safety Feature
Emergency Stop Button, Limit Switches

Placement Range
Up to 18 meters Radius

Operating Temperature
-10C to +45C

Usage
Suitable for Urban and Large-scale Concrete Placement Projects

Power Source
Electric

About Static Boom Placer

A Static Boom Placer is a highly efficient concrete placing system designed to deliver concrete accurately across construction sites while reducing manual effort and improving productivity. Commonly used in high-rise buildings, bridges, tunnels, dams, and large commercial projects, the equipment ensures smooth and continuous concrete placement in hard-to-reach areas. Manufactured using high-quality steel and precision-engineered components, static boom placers offer outstanding durability, stability, and long-term performance under demanding site conditions. The equipment can be integrated with concrete pumps to achieve faster placement while minimizing material wastage and labor requirements. Its flexible boom design allows wide coverage and precise concrete distribution, ensuring consistent quality throughout the construction process. Easy installation, low maintenance requirements, and robust construction make the Static Boom Placer an ideal solution for contractors seeking efficient, safe, and cost-effective concrete placement in modern construction projects.

FAQs

1. What is a Static Boom Placer used for?
It is used for accurate and efficient placement of concrete in construction projects.

2. Can it be connected to a concrete pump?
Yes, Static Boom Placers are designed to work seamlessly with concrete pumps.

3. Where are Static Boom Placers commonly used?
They are widely used in high-rise buildings, bridges, tunnels, dams, and commercial construction projects.

4. What are the advantages of a Static Boom Placer?
It improves concrete placement accuracy, reduces labor, increases productivity, and minimizes material wastage.

5. Is a Static Boom Placer easy to maintain?
Yes, its robust design requires minimal maintenance while ensuring reliable long-term performance.

Designed for Urban and Large-scale Construction

The Static Boom Placer is purpose-built for challenging locations in bustling city projects and expansive construction sites. With its stationary base and an 18-meter reach, it is ideal for delivering concrete precisely in hard-to-access spots, enhancing operational efficiency for contractors and builders.

Superior Safety and Easy Operation

Safety is prioritized through features like emergency stop buttons and integrated limit switches. Whether operated remotely or manually, the semi-automatic control system ensures that users can manage placement safely and efficiently, while air-cooled motors and hydraulic mechanisms provide reliable performance under demanding site conditions.

Efficient and Robust Performance

With a motor power of 15 kW and a capacity of up to 90 m3/h, this boom placer is engineered for high productivity. It handles heavy workloads, offers continuous 360-degree swivel, and can be adjusted smoothly to reach up to 18 meters in height, making it a valuable asset for ambitious construction projects.

FAQ's of Static Boom Placer:

Q: How does the Static Boom Placer enhance concrete placement efficiency at construction sites?

A: The Static Boom Placer streamlines concrete placement by offering an 18-meter reach with a 360-degree continuous rotation, allowing for quick and precise positioning of concrete at difficult locations. This significantly reduces manual labor and speeds up construction timelines.

Q: What safety features are integrated into this boom placer?

A: Safety is ensured through the inclusion of an emergency stop button and multiple limit switches. These features help prevent accidents during operation and support safe handling during both remote and manual control.

Q: When is it ideal to use this boom placer in construction projects?

A: This boom placer is particularly suited for use during large-scale pours on high-rise buildings, bridges, and infrastructure projects where concrete needs to be delivered efficiently and at extended heights or radii beyond the reach of traditional methods.

Q: Where can the Static Boom Placer be installed?

A: Designed with a stationary base, the boom placer is best mounted on prepared surfaces at construction sites, especially in urban and challenging environments where close proximity and precise placement are required.

Q: What is the process for operating the boom placer?

A: Operation involves positioning the boom manually or via remote, activating the hydraulic system to extend or retract the sections as needed, and controlling the flow of concrete through the 125 mm pipe. All functions are supported by a user-friendly control panel and semi-automatic features.

Q: How does regular maintenance contribute to the longevity of this machine?

A: The boom placer is constructed from high-grade steel and features an air-cooled motor, resulting in low maintenance requirements. Regular checks on the hydraulic systems, safety devices, and coated surfaces ensure durability and uninterrupted performance, even in demanding conditions.

Q: What are the main benefits of choosing this boom placer for concrete delivery?

A: Key advantages include its extended placement range, robust lifting speed of 30 m/min, high flow rate, and minimal maintenance needs. These factors together provide contractors with reliable solutions for challenging concrete placement demands, especially in India's construction sector.
